- Frame: 6061 Aluminum, 100mm Travel
- Fork: Manitou J-Unit 20", TS Air, Alloy Steerer 120mm Travel
- Rear Shock: X-Fusion 02 Pro R
- Headset: FSA #57 E
- Grips: Norco Jr 92mm, lock on
- Handle Bar: Alloy, 620mm, 15mm Rise
- Stem: 35mm reach MTB
- Seat Post: Norco 6061 Alloy Double Bolt Head, 30.9mm
- Seat Post Clamp: Norco Alloy QR
- Saddle: Norco Jr. MTB Saddle
- Front Brake: Tektro HD-M276 Hydraulic, Jr lever, 160mm
- Rear Brake: Tektro HD-M276 Hydraulic, Jr lever, 160mm
- Shifter Rear: Shimano Deore SL-M6000 10 speed
- Shifter Front: -
- Front Derailleur: -
- Rear Derailleur: Shimano Zee RD-M640
- Cassette: Shimano Deore CS-HG50 11-36T
- Chain: KMC X10
- Crankset: Samox AM38J 3 piece 140mm, narrow/wide 30T
- Bottom Bracket: square taper
- Chain Tensioner: -
- Pedals: Jr flat resin, metal pins
- Front Hub: Alloy Sealed Bearing, 9x100mm
- Front Hub Skewer/Axle: Alloy QR
- Rear Hub: Alloy 12x148mm Boost
- Rear Hub Skewer/Axle: 12x142mm TA (Fits Norco 148mm frame)
- Spokes/Nipples: Stainless 14g, Black
- Rims: Alloy Double Wall Disc
- Front Tyre: Vee Rubber Crown Gem 20x2.25", Skinwall
- Rear Tyre: Vee Rubber Crown Gem 20x2.25", Skinwall
